RuggedT – 12.2 inch Industrial Tablet W3J
12.2 inch Rugged Tablet W3J
W3J is a 12.2 inch rugged tablet, has Win 10 Pro OS and up to 16G+128G specification, SSD upgrade is also optional. As the biggest Windows OS rugged tablet among our devices, W3J drew lots of attention when it fist launched since it is born for desktop or platform working environment.
| W3J Specification | |
|---|---|
| CPU | Intel JASPER LAKE N5105 |
| Memory | RAM:8GB/16GB,ROM:128GB |
| OS | Windows 10 Pro |
| Display | 12.2 inch IPS screen, 1920*1200, 280 nits |
| Touch Panel | 10 points Capacitive，G+G，Rigidity: above 7H-Anti-scratch |
| Dimenson | 339.3*230.3*26 mm |
| Weight | 1500g |
| Battery | 6300 mAH, 7.4V |
| Camera | 2MP+8MP |
| WiFi | 802.11(a/b/g/n/ac) dual frequency 2.4G+5.8G WIFI |
| 3G/4G frequency | LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8 |
| GPS | U-blox M8Q ,Support:GPS, Beidou module, glonass |
| NFC(optional) | 13.56 MHz |
| 2D scanner(optional) | |
| USB port | USB 3.0*1 (Host) for Windows; USB Type-C*1 for data transfer&charging |
| POGO-PIN | POGO-PIN coonector for data transmission and charging |
| HDMI | HDMI 1.4a mini*1 |
| Fingerprint | Fingerprint module*1 |
| RS232 (DB9) | Optional |
| RJ45 | RJ45 port*1 |
| TF Card | support SDHC/SDXC x1 max: 512G |
| SIM Card | 3G/4G, NANO SIM card slot*1 |
| Operating Temperature | -20℃~60℃/ 14 °F to 122 °F |
| Storage Temperature | -30 °C to 70 °C/ -22 °F to 158 °F |
| Humidity | 5%RH~95%RH(non condensing) |
| IP Grade | IP 65 |
| Drop Height | 1.2m composite wood floors, in operation status |
REPLACEABLE BATTERY
W3J is with 6300 mAh 7.4V battery, which is durable as 12600 mAh/3.7V battery. Moreover, it can support hot-swappable battery, docking station charging and vehicle mount charging, so there is no need to worry about its battery working life.
Bigger screen, bigger platform
If you are looking for a big screen Windows rugged tablet, then W3J will be our first recommendation. Its 12.2 inch screen will be really helpful in lots of industries such as factory, car inspection, security and so on. With Intel JASPER LAKE N5105 powerful CPU, it can help you to handle many tasks.
Rugged from within
W3J is IP 65 and MIL-STD-810G certified, can also work in extreme working environments and temperatures. It is not only “looks like” rugged, but is build-up rugged from within. Every components were designed and adjusted for many times back in draft, and we just wanted to produce as the tough tablet to withstand different harsh scenarios.
Rugged T Will Ensure Final Inspection and Strong Package
There is a strict QC procedure on the rugged devices’ production line, but before ship out, we will also inspect all devices thoroughly and send you a report to ensure they are 100% qualified. Moreover, we will pack your devices with reinforce boxes and proper buffering to make sure you will received them intact!
Docking station
Vehicle charger
Vehicle mount
Stylus
