RuggedT – 12.2 inch Industrial Tablet W3J

12.2 inch Rugged Tablet W3J

W3J is a 12.2 inch rugged tablet, has Win 10 Pro OS and up to 16G+128G specification, SSD upgrade is also optional. As the biggest Windows OS rugged tablet among our devices, W3J drew lots of attention when it fist launched since it is born for desktop or platform working environment.

W3J Specification
Memory RAM:8GB/16GB,ROM:128GB
OS Windows 10 Pro
Display 12.2 inch IPS screen, 1920*1200, 280 nits
Touch Panel 10 points Capacitive,G+G,Rigidity: above 7H-Anti-scratch
Dimenson 339.3*230.3*26 mm
Weight 1500g
Battery 6300 mAH, 7.4V
Camera 2MP+8MP
WiFi 802.11(a/b/g/n/ac) dual frequency 2.4G+5.8G WIFI
3G/4G frequency LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8
GPS U-blox M8Q ,Support:GPS, Beidou module, glonass
NFC(optional) 13.56 MHz
2D scanner(optional)
USB port USB 3.0*1 (Host) for Windows; USB Type-C*1 for data transfer&charging
POGO-PIN POGO-PIN coonector for data transmission and charging
HDMI HDMI 1.4a mini*1
Fingerprint Fingerprint module*1
RS232 (DB9) Optional
RJ45 RJ45 port*1
TF Card support SDHC/SDXC x1 max: 512G
SIM Card 3G/4G, NANO SIM card slot*1
Operating Temperature -20℃~60℃/ 14 °F to 122 °F
Storage Temperature -30 °C to 70 °C/ -22 °F to 158 °F
Humidity 5%RH~95%RH(non condensing)
IP Grade IP 65
Drop Height 1.2m composite wood floors, in operation status


W3J is with 6300 mAh 7.4V battery, which is durable as 12600 mAh/3.7V battery. Moreover, it can support hot-swappable battery, docking station charging and vehicle mount charging, so there is no need to worry about its battery working life.

Bigger screen, bigger platform

If you are looking for a big screen Windows rugged tablet, then W3J will be our first recommendation. Its 12.2 inch screen will be really helpful in lots of industries such as factory, car inspection, security and so on. With Intel JASPER LAKE N5105 powerful CPU, it can help you to handle many tasks.

Rugged from within

W3J is IP 65 and MIL-STD-810G certified, can also work in extreme working environments and temperatures. It is not only “looks like” rugged, but is build-up rugged from within. Every components were designed and adjusted for many times back in draft, and we just wanted to produce as the tough tablet to withstand different harsh scenarios.

Previous slide
Next slide

Rugged T Will Ensure Final Inspection and Strong Package

There is a strict QC procedure on the rugged devices’ production line, but before ship out, we will also inspect all devices thoroughly and send you a report to ensure they are 100% qualified. Moreover, we will pack your devices with reinforce boxes and proper buffering to make sure you will received them intact!

Docking station

Vehicle charger

Vehicle mount
