RuggedT – 10.1 inch Industrial Tablet W1J
10.1 inch Rugged Tablet W1J
W1J is a 10.1 inch rugged tablet, has Win 10 Pro OS and up to 16G+128G specification, SSD upgrade is also optional. With powerful performance, W1J can withstand harsh working environment and multiple tasks. Replaceable battery will be a life saver during the long-time outdoor tasks.
| W1J Specification | |
|---|---|
| CPU | Intel JASPER LAKE N5105 |
| Memory | RAM:8GB/16GB,ROM:128GB |
| OS | Windows 10 Pro |
| Display | 10.1 inch IPS screen, 1920*1200, 330 nits |
| Touch Panel | 10 points Capacitive，G+G，Rigidity: above 7H-Anti-scratch |
| Dimenson | 289.9*196.7*27.4mm |
| Weight | 1140g |
| Battery | 5000 mAH, 7.4V |
| Camera | 2MP+8MP |
| WiFi | 802.11(a/b/g/n/ac) dual frequency 2.4G+5.8G WIFI |
| 3G/4G frequency | LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8 |
| GPS | U-blox M8Q ,Support:GPS, Beidou module, glonass |
| NFC(optional) | 13.56 MHz |
| 2D scanner(optional) | |
| USB port | USB 3.0*1 (Host) for Windows; USB Type-C*1 for data transfer&charging |
| POGO-PIN | POGO-PIN coonector for data transmission and charging |
| HDMI | HDMI 1.4a mini*1 |
| Fingerprint | Fingerprint module*1 |
| RS232 (DB9) | Optional |
| RJ45 | RJ45 port*1 |
| TF Card | support SDHC/SDXC x1 max: 512G |
| SIM Card | 3G/4G, NANO SIM card slot*1 |
| Operating Temperature | -20℃~60℃/ 14 °F to 122 °F |
| Storage Temperature | -30 °C to 70 °C/ -22 °F to 158 °F |
| Humidity | 5%RH~95%RH(non condensing) |
| IP Grade | IP 65 |
| Drop Height | 1.2m composite wood floors, in operation status |
REPLACEABLE BATTERY
W1J is with 5000 mAh 7.4V battery, which is durable as 10000 mAh/3.7V battery. Consider the lots of customers need to remain working when replacing battery, so we made W1J to integrate a small battery so the battery is hot-swappable. Now nothing can stop you from working tasks!
IP 65& MIL-STD-810G tough&rugged
W1J passed IP 65 and MIL-STD-810G, and its drop resistance can also reach 1.2 meter height. We understand the importance to have a reliable device during the harsh work, so producing the good quality rugged device to work with your together is our first goal.
Professional work partner
We don’t want W1J just to be a simple “rugged tablet”, but a powerful helper that can support multiple projects such as fleet management, factory management, network analysis and so on. With its expansion ports, it can be your professional work partners in different industries!
Rugged T Will Ensure Final Inspection and Strong Package
There is a strict QC procedure on the rugged devices’ production line, but before ship out, we will also inspect all devices thoroughly and send you a report to ensure they are 100% qualified. Moreover, we will pack your devices with reinforce boxes and proper buffering to make sure you will received them intact!
Docking station
Vehicle charger
Vehicle mount
Stylus
