RuggedT – 10.1 inch Industrial Tablet W1J

10.1 inch Rugged Tablet W1J

W1J is a 10.1 inch rugged tablet, has Win 10 Pro OS and up to 16G+128G specification, SSD upgrade is also optional. With powerful performance, W1J can withstand harsh working environment and multiple tasks. Replaceable battery will be a life saver during the long-time outdoor tasks.

W1J Specification
CPU Intel JASPER LAKE N5105
Memory RAM:8GB/16GB,ROM:128GB
OS Windows 10 Pro
Display 10.1 inch IPS screen, 1920*1200, 330 nits
Touch Panel 10 points Capacitive,G+G,Rigidity: above 7H-Anti-scratch
Dimenson 289.9*196.7*27.4mm
Weight 1140g
Battery 5000 mAH, 7.4V
Camera 2MP+8MP
WiFi 802.11(a/b/g/n/ac) dual frequency 2.4G+5.8G WIFI
3G/4G frequency LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8
GPS U-blox M8Q ,Support:GPS, Beidou module, glonass
NFC(optional) 13.56 MHz
2D scanner(optional)
USB port USB 3.0*1 (Host) for Windows; USB Type-C*1 for data transfer&charging
POGO-PIN POGO-PIN coonector for data transmission and charging
HDMI HDMI 1.4a mini*1
Fingerprint Fingerprint module*1
RS232 (DB9) Optional
RJ45 RJ45 port*1
TF Card support SDHC/SDXC x1 max: 512G
SIM Card 3G/4G, NANO SIM card slot*1
Operating Temperature -20℃~60℃/ 14 °F to 122 °F
Storage Temperature -30 °C to 70 °C/ -22 °F to 158 °F
Humidity 5%RH~95%RH(non condensing)
IP Grade IP 65
Drop Height 1.2m composite wood floors, in operation status

REPLACEABLE BATTERY

W1J is with 5000 mAh 7.4V battery, which is durable as 10000 mAh/3.7V battery. Consider the lots of customers need to remain working when replacing battery, so we made W1J to integrate a small battery so the battery is hot-swappable. Now nothing can stop you from working tasks!

IP 65& MIL-STD-810G tough&rugged

W1J passed IP 65 and MIL-STD-810G, and its drop resistance can also reach 1.2 meter height. We understand the importance to have a reliable device during the harsh work, so producing  the good quality rugged device to work with your together is our first goal.

Professional work partner

We don’t want W1J just to be a simple “rugged tablet”, but a powerful helper that can support multiple projects such as fleet management, factory management, network analysis and so on. With its expansion ports, it can be your professional work partners in different industries!

Previous slide
Next slide

Rugged T Will Ensure Final Inspection and Strong Package

There is a strict QC procedure on the rugged devices’ production line, but before ship out, we will also inspect all devices thoroughly and send you a report to ensure they are 100% qualified. Moreover, we will pack your devices with reinforce boxes and proper buffering to make sure you will received them intact!

Docking station

Vehicle charger

Vehicle mount

Stylus
